Avolites – New Diamond 7 (D7-215)
15 motor playback faders, 15 encoder playbacks
2 x 14” capacitive touchscreens with adjustable brightness
Dual, motorised, touch-sensitive, master cue-list and sequence faders with 9 control buttons
Fits into a Peli-Air Case 1650, total weight under European hold limit

Generative, animation-based pixel mapping

Quicksketch labelling for ultimate personalisation
Powerful multi-user networking with any Titan console
Create huge effects in seconds with Key Frame Shapes
Feature-packed cue lists supporting macros, tracking, autoloads, timecode and more
Expand DMX channel capacity with Titan Net Processors
Synergy-ready. Add any Ai product to unlock seamless video integration

15 motorised touch-sensitive faders, with designer fader cap and RGB fader indicator
15 ultra high resolution touch sensitive playback encoders with push function, and RGB encoder indicator
5 x custom RGB backlit optical attribute encoders
Programming buttons all RGB backlit, short travel Cherry® MX Low Profile switches
2 x 14” 850 nits 1920×1200 capacitive touch main screens with adjustable brightness, mounted on folding panel
Dedicated level wheel and onscreen level indication
Full custom backlit QWERTY keyboard in drawer, keys identical to program panel
LED strip reading light in panel above screens and over rear panel
4x isolated DMX outputs via 5 pin XLR connectors
Ethernet switch with 4x Neutrik XLR on the Primary network port, Secondary network port
MIDI in, Loop & Out port in DIN 5, SMTP in/loop out, Foot trigger input, Audio trigger Input,
SMPTE RTU Timecode in and Loop out via 3 pin XLR with transformer isolation
GPIO with 4 inputs and 4 outputs on 15 Pin D sub connector
Supports two additional external DisplayPort 1920*1080 touchscreens
